30 mAh Battery LP551011 – 3.7 V Small Battery
Small Volume Pricing (USD $)
|QTY BREAK||UNIT PRICE|
Contact us for a quotation for production quantities, customizations and integration such as custom wire length or with JST/ Molex connectors.
30mAh Lipo Battery LP551011 4mm Thickness
Lipoly Batteries Custom design lithium ion battery, 7.4 V / 11.1 V battery pack. 18 years manufacturer of military, robotic, medical, instrument. More than 3000 Successful Cases. Custom 3.7 V Slim Lipo Battery Design support. 24*7 Services.
- Factory price& High quality
- Good consistency, low self discharge
- Light weight, small size
- High stability
- High discharge rate
- Quality and security guaranted, with CE, UN38.3 approval
|LiPo Battery Mechanical Chracteristics|
|Lithium Battery PCM||Yes|
|Battery Weight||appr. 4g|
|Lipo Battery Dimension||5.5mm*10mm*11mm|
|Lithium Battery Electrical Specification|
|Lipo Battery Rated Capacity||30mAh min, 35mAh typ.|
|Lithium Polymer Battery Nominal Voltage||3.7V|
|Lipo Battery Wat-Hour Rating||0.111Wh|
|Max. Operating Voltage Range||2.75V to 4.20V|
|Max. Charge Voltage||4.2V ±50mV|
|Max. Charge Current||15mA|
|Discharge Cut Off||2.75V|
|Lipo Battery Expected Cycle Life||500 cycles ≥ 80%|
|@ (0.5C/0.5C) @ 23±5°C|
1.Payment methods : Paypal, T/T
1.Delivery: DHL door to door 10-15 work days.
2.Item will be shipped within 5-7 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
5.In order to ensure you receive your order tax free upon import, we will declare it with a lower value, pls be noted, thanks!
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the Lithium polymer battery such as: Capacity, Sizes Applications, Voltage, Leads wire, Terminals. The minimum order quantity for custom lipo battery is 5000 pieces.
3.7 v small battery, 30 mah battery, 3.7 volt thin lipo battery
